Who says trail bikes can’t pack a punch? Who says trails bikes can’t pedal all day but still give you confidence when the trail gets nasty. This is the all new Katipo Trail and it is ready to redefine your perception on what a Trail bike can do. Does it climb like a trail bike? Hell yes. Does it descend like a trail bike? Hell no. The Katipo Trail will make you feel guilty about how easy riding becomes. It’s a lively Swiss army knife that will keep giving even when you think you are at your boundaries.

Wheelsize: 29 inch

Travel: 150 mm front, 140 mm rear

Price (including tax):

Origin build: € 4995.- (frame + shock + full drive train)

Voyager build: € 7495.-

Deluxe build: € 8395.-


Do you have specific customization requests? Just let us know.

ORIGIN (frame + shock + drive train)

Gearbox: Pinion C1.12 12 speed
-If you prefer C1.9 9 speed gearbox please mention in order notes in your shopping cart-
Belt tensioner + belt guard: Pinion BT1
Cranks: Pinion
Belt + sprockets: Gates Carbon Drive
Rear shock: FOX factory kashima X2 air (enduro) or Float-X (trail)
-If you prefer a Fox DHX2 coil shock please mention in order notes in your shopping cart-

VOYAGER

Gearbox: Pinion C1.9xr 9 speed
-If you prefer C1.12 12 speed gearbox just send us a message for an upgrade price-
Belt tensioner + belt guard: Pinion BT1
Cranks: Pinion
Belt + sprockets: Gates Carbon Drive
Fork: FOX 36 factory kashima GRIP2
-If you prefer a Fox 38 fork just send us a message for an upgrade price-
Headset: Cane creek 40
Stem: Zerode 45mm
Bars: Truvativ alu
Grips: Zerode lock on
Seatpost: Bike Yoke Revive (depending on size)
Saddle: WTB Volt
Tires: Maxxis
Hubs: Hope pro5
Rims: Hope Fortus
Brakes: Magura MT5, 203/180 rotors
Rear shock: FOX factory kashima X2 (enduro) or Float-X (trail)
-If you prefer a Fox DHX2 coil shock just send us a message for an upgrade price-

DELUXE

Gearbox: Pinion C1.12 12 speed
-If you prefer C1.9 9 speed gearbox please mention in order notes in your shopping cart-
Belt tensioner + belt guard: Pinion BT1
Cranks: Pinion
Belt + sprockets: Gates Carbon Drive
Fork: FOX 36 factory kashima GRIP2
-If you prefer Fox 38 fork please mention in order notes in your shopping cart-
Headset: Cane creek 40
Stem: Zerode 45mm
Bars: Zerode carbon
Grips: Zerode lock on
Seatpost: Bike Yoke Revive 160/ 185/ 213 mm (depending on size)
Saddle: WTB Volt
Tires: Maxxis
Hubs: Hope Pro5
Rims: South Industries carbon Enduro handbuilt
Brakes: Magura MT5, 203/180 rotors
Rear shock: FOX factory kashima X2 (enduro) or Float-X (trail)
-If you prefer a Fox DHX2 coil shock please mention in order notes in your shopping cart-

See our sizing chart here.

Are you looking for small or medium? Check our Taniwha models!

LARGE

SEAT TUBE LENGTH: 460mm
SEAT TUBE ANGLE: 76°
HEAD TUBE LENGTH: 110mm
HEAD TUBE ANGLE: 65°
CHAINSTAY LENGTH: 435mm
WHEELBASE: 1240mm
STACK: 603mm
REACH: 475mm
BB DROP: 29mm

EXTRA LARGE

SEAT TUBE LENGTH: 490mm
SEAT TUBE ANGLE: 76°
HEAD TUBE LENGTH: 120mm
HEAD TUBE ANGLE: 65°
CHAINSTAY LENGTH: 435mm
WHEELBASE: 1274mm
STACK: 612mm
REACH: 505mm
BB DROP: 29mm

- Tann

- Burgundy Red

- Sharknado Grey

- Peppermint Rascal (only XL left)

FRAME MATERIAL: Carbon Fibre. Internal cable routing for gears and dropper post.
TRAVEL: 140mm
WHEEL SIZE: 29”
SEATPOST: 31.6mm
SEATPOST CLAMP: 34.9mm
REAR SHOCK: 230mm eye to eye x 60mm stroke. 22.2mm x 8mm reducer.
HEADSET: Tapared (1.5 - 1 1/8 inch)
BRAKE MOUNT: 160mm PM
DRIVE TRAIN: Pinion C.Line Gearbox
REAR HUB: 142mm x 12mm (single speed)
WEIGHT: 2625 grams (large). Also see weight info here.

Leadtime depends on your product and requests, on average 2-3 working weeks from order to delivery.

Free pick up option is available at our EU site in Heerlen (NL).

Shipping rates Europe:

Full bike build to EU: € 69.90

Origin/ frame to EU: € 39.90

Full bike build outside EU: € 99.90

Origin/ frame outside EU: € 69.90

Build
Size
Color
ASK YOUR QUESTIONS

If you’re thinking seriously about getting your hands on this bike, but you would like to have a good chat beforehand, just hit the link below, fill in the quick form and a member of our team will email you. Specific customization requests? Just let us know.

wide single speed hub

Wider flange spacing than anything super boost and symmetrical spoke angles means your wheel is ultra stiff. It also means you can build up lighter wheels.

world renowned zerode suspension

It’s no lie. We are renowned for the suspension performance of our bikes so don’t think the Katipo is any different.

big and massive

We didn’t hold back on the sizes. With a reach of up to 505mm the Katipo will keep even the tallest giraffes happy.

belt driven

Unchain your adventure. We partnered with Gates - THE a global leader in belt drive technologies, offering grease-free, low maintenance, and hassle-free ownership. Leave the chain tool at home and join the revolution.

simple

There’s no dinner plate sized cassettes or fragile derailleurs to snap off. It’s just simple, durable and reliable.

gearbox driven

At the heart of the Katipo is the Pinion Gearbox. Instantaneous shifting, low maintenance and improved traction are just a few of the benefits the gearbox provides.

happy riders worldwide

★★★★★

I sure as hell felt like I was full of indestructible teenage courage & angst. With traction for days & tank-like stability, you can go wherever you want when you're riding the Taniwha. The bike has a stability to it, or maybe a calmness is a better way to put it, that makes a rider feel like they're more skilled & brave.

Mike Levy - PinkBike
Canada
★★★★★

I was instantly flashed by the performance of this bike. All the little things i disliked with my eagle drivetrain are gone... shifting while standing (top of the hill) or smashing a couple of gears.. I dont think I am ever going back to a "regular" drivetrain.

Samuel Tertel
Germany
★★★★★

I just returned from 4 weeks riding in Italy, and I took my Katipo. The bike performed flawlessly in every situation it put it in. I have been super happy with the Katipo from day 1 out of the box and this trip cemented my happiness!

Tim Miller
UK
★★★★★

This thing handles WAY more than it should for a Trail bike!

David Hoganson
Snowshoe, USA
