Taniwha Trail
It’s time to rethink the capabilities of a trail bike. Designed to pedal and then pedal some more while providing more than enough capability when things get rough, the Taniwha Trail is up for some serious fun.
It doesn’t shy away from trail jibs, nose bonks and airtime but if you like to keep your wheels on the ground it’s your friend too. The Taniwha Trail provides an extremely quiet ride that will put a smile on your face ride after ride.
Wheelsize: 27,5 inch
Travel: 150 mm front, 140 mm rear
Price (including tax):
Origin build: € 4995.- (frame + shock + full drive train)
Voyager build: € 7495.-
Deluxe build: € 8395.-
Do you have specific customization requests? Just let us know.
ORIGIN (frame + shock + drive train)
Gearbox: Pinion C1.12 12 speed
-If you prefer C1.9 9 speed gearbox please mention in order notes in your shopping cart-
Belt tensioner + belt guard: Pinion BT1
Cranks: Pinion
Belt + sprockets: Gates Carbon Drive
Rear shock: FOX factory kashima X2 air (enduro) or Float-X (trail)
-If you prefer a Fox DHX2 coil shock please mention in order notes in your shopping cart-
VOYAGER
Gearbox: Pinion C1.9xr 9 speed
-If you prefer C1.12 12 speed gearbox just send us a message for an upgrade price-
Belt tensioner + belt guard: Pinion BT1
Cranks: Pinion
Belt + sprockets: Gates Carbon Drive
Fork: FOX 36 factory kashima GRIP2
-If you prefer a Fox 38 fork just send us a message for an upgrade price-
Headset: Cane creek 40
Stem: Zerode 45mm
Bars: Truvativ alu
Grips: Zerode lock on
Seatpost: Bike Yoke Revive (depending on size)
Saddle: WTB Volt
Tires: Maxxis
Hubs: Hope pro5
Rims: Hope Fortus
Brakes: Magura MT5, 203/180 rotors
Rear shock: FOX factory kashima X2 (enduro) or Float-X (trail)
-If you prefer a Fox DHX2 coil shock just send us a message for an upgrade price-
DELUXE
Gearbox: Pinion C1.12 12 speed
-If you prefer C1.9 9 speed gearbox please mention in order notes in your shopping cart-
Belt tensioner + belt guard: Pinion BT1
Cranks: Pinion
Belt + sprockets: Gates Carbon Drive
Fork: FOX 36 factory kashima GRIP2
-If you prefer Fox 38 fork please mention in order notes in your shopping cart-
Headset: Cane creek 40
Stem: Zerode 45mm
Bars: Zerode carbon
Grips: Zerode lock on
Seatpost: Bike Yoke Revive 160/ 185/ 213 mm (depending on size)
Saddle: WTB Volt
Tires: Maxxis
Hubs: Hope Pro5
Rims: South Industries carbon Enduro handbuilt
Brakes: Magura MT5, 203/180 rotors
Rear shock: FOX factory kashima X2 (enduro) or Float-X (trail)
-If you prefer a Fox DHX2 coil shock please mention in order notes in your shopping cart-
See our sizing chart here.
Are you looking for a bigger size? Check our Katipo models!
SMALL
SEAT TUBE LENGTH: 400mm
SEAT TUBE ANGLE: 75.5°
HEAD TUBE LENGTH: 110mm
HEAD TUBE ANGLE: 66°
CHAINSTAY LENGTH: 437mm
WHEELBASE: 1159mm
STACK: 579mm
REACH: 420mm
BB DROP: 0
MEDIUM
SEAT TUBE LENGTH: 430mm
SEAT TUBE ANGLE: 75.5°
HEAD TUBE LENGTH: 120mm
HEAD TUBE ANGLE: 66°
CHAINSTAY LENGTH: 437mm
WHEELBASE: 1191mm
STACK: 587mm
REACH: 445mm
BB DROP: 0
LARGE
SEAT TUBE LENGTH: 470mm
SEAT TUBE ANGLE: 75.5°
HEAD TUBE LENGTH: 130mm
HEAD TUBE ANGLE: 66°
CHAINSTAY LENGTH: 437mm
WHEELBASE: 1225mm
STACK: 594mm
REACH: 475mm
BB DROP: 0
- Matte Obsidian Black
- Blue Sunday
FRAME MATERIAL: Carbon Fibre. Internal cable routing for gears and dropper post.
TRAVEL: 140mm
WHEEL SIZE: 27.5”
SEATPOST: 31.6mm
SEATPOST CLAMP: 34.9mm
REAR SHOCK: 210mm eye to eye x 55mm stroke. 22.2mm x 8mm reducer.
HEADSET: Tapared (1.5 - 1 1/8 inch)
BRAKE MOUNT: 160mm PM
DRIVE TRAIN: Pinion C.Line Gearbox
REAR HUB: 142mm x 12mm (single speed)
WEIGHT: 2730 grams (large). Also see weight info here.
Leadtime depends on your product and requests, on average 2-3 working weeks from order to delivery.
Free pick up option is available at our EU site in Heerlen (NL).
Shipping rates Europe:
Full bike build to EU: € 69.90
Origin/ frame to EU: € 39.90
Full bike build outside EU: € 99.90
Origin/ frame outside EU: € 69.90
